CL22R

OUTDOOR MULTICOLORED CAMPING LANTERN

Fenix CL22R is a compact portable camping lantern that will elevate your camping experience to the next level. Powered by a built-in2600mAh battery, you can charge the lantern via the USB Type-C charging port on the lantern's outer case. This versatile lantern offers 360°lighting, down lighting, red light, and colorful atmosphere lights to satisfy various needs on different occasions, creating a romantic ambiance and providing engaging experiences for users. With a maximum output of 500 lumens and IP65-rated protection, the CL22R is a fantastic lighting tool for camping with loved ones.

  • 500 LM Lumens
  • 80 M Range
  • 200 H Run Time
  • IP66 Water Resistant
Size
1.50'' × 1.65'' × 4.53'' / 38 x 42 x 115 mm
Weight
4.76 oz / 135 g (including battery)
Battery Type
2600mAh built-in battery

FEATURES

  • 500 Lumen Max Output

    500 lumens max combined output.

  • LED Technology for Longevity

    Utilizes one COB, one RedslightSC1818C cold white LED, and twelve WS2812B-3535 LEDs; with a lifespan of 50,000 hours each.

  • Lighting Modes: 360° vs Down Light

    360°lighting mode has a max beam diameter of 20 meters, while Down light mode has a max beam distance of 80 meters. Both modes can be used together.

  • Lighting Solutions: White and Red Sources

    White and red light sources for various lighting demands.

  • Colorful Romantic Atmosphere Lights

    Bottom colorful atmosphere lights create a romantic ambiance.

  • Built-in 2600mAh Battery

    Powered by a built-in 2600mAh battery.

  • Universal USB Type-C Charging and Battery Indicator

    Universal USB Type-C charging port and battery level indication.

  • Rotary and Electronic Switches for Quick Operation

    Rotary switch and electronic switch for easy and fast operation.

  • Convenient Carry with Hanging Loop and Snap Hook

    Built-in hanging loop and included double snap hook allow for easy carry and hanging.

  • IP65 Protection with Impact Resistance

    IP65-rated protection and 1.5 meters impact resistance.

Take a Closer Look

FAQS

Contact Us
Q1. What is the product positioning of CL22R? What are the key features of CL22R?
The Fenix CL22R is a compact multifunctional atmosphere lantern. Its key features include:
1. 500 lumens max combined output.
2. Colorful atmosphere lights at the bottom create a romantic ambiance.
3. Down light can be used as a flashlight with a max beam distance of 80 meters.
Q2. What kind of LEDs’ are used in CL22R? Does Fenix offer to replace LED?
Utilizes one COB, one Redslight SC1818C cold white LED, and twelve WS2812B-3535 LEDs; with a lifespan of 50,000 hours each.
Fenix does not provide LED replacement services for the time being, and users are not recommended to replace the LEDs independently, which may affect product performance and cause product damage.
Q3. What is the color temperature of CL22R?
The color temperature of the 360° lighting mode is 3000K. The color temperature of the Down light mode is 6500K.
Q4. What is the working voltage and working current of CL22R?
Working voltage: 2.8V - 4.2V. Max working current is 2A.
Q5. Is CL22R rechargeable? How long is the charging time?Is the lantern still waterproof without the anti-dust cap?
Yes, CL22R is rechargeable with a USB Type-C port. The normal charging time of the lantern is approximately 3 hours from depleted to fully charged with a 5 V/1 A or higher power charging adapter. No, therefore once charging is completed, be sure to close the anti-dust cover to maintain the dustproof and waterproof ability.
Q6. Why does the CL22R downshift to a lower mode after being used for a while and the higher mode cannot be selected?
There are two reasons:
1. Intelligent Overheat Protection
The lantern will accumulate a lot of heat when used at high output levels for extended periods. When the lantern reaches a temperature of 50°C/122°F or above, it will automatically step down a few lumens every to reduce the temperature. When the temperature drops below 50°C/122°F, the lantern will gradually recall the preset output level.
2. Low-voltage Warning
When the voltage level drops below the preset level, one of the battery level indicators constantly blinks to remind you to timely recharge the battery. To ensure normal use, the lantern will not turn off automatically and will work till the battery level runs out.
Q7. Why does the CL22R happen to flicker?
The lantern may flicker, shine intermittently or even fail to illuminate due to poor battery level. Please recharge the lantern.
If this method doesn't work, please contact your authorized distributor.
Q8. What are the optional accessories for CL22R?
The included double snap hook.
Q9. What should I do when the CL22R needs repair?
1. 15-day replacement: Fenix will replace identical or equal products with documented manufacturing defects within 15 days of purchase.
2. 2-year free repair: Fenix will repair a light free of charge within 2 years (rechargeable battery and other accessories: 1 year) of purchase if problems develop with normal use.
3. Lifetime limited warranty: If repair is required after 2 years from the date of purchase, Fenix will charge for parts. The total repair fee is dictated by the cost of the replaced materials.
4. Warranty certificate: Please keep the warranty card in contacting the authorized distributors for after-sale maintenance, Fenix will provide service support to the distributors.
