C5 V2.0

HIGH-PERFORMANCE OUTDOOR FLASHLIGHT

The Fenix C5 V2.0 packs a maximum output of 1800 lumens and provides a maximum beam distance of 327 meters. It is powered by an included 2600mAh 18650 rechargeable battery and features convenient USB-C direct charging, allowing you to recharge it on the go. Thanks to its upgraded, thicker light body, the flashlight offers exceptional durability and impact resistance, easily enduring everyday bumps and knocks. Whether for everyday carry, household tasks, or outdoor adventures, it stands out as a versatile and reliable choice for any user.

  • 1800 LM Lumens
  • 327 M Range
  • 117.83 H Run Time
  • IP68 Water Resistant
Size 5.32'' × 1.34'' × 1.00''/135 × 34 × 25.5 mm.
Weight 6.34 oz/179.6 g(including battery).
Battery Type ARB-L18-2600


FEATURES

  • High lumen, long range   1800 lumens maximum output, 327 meters maximum beam distance.
  • USB Type-C port  Supports up to 2A charging; 2 hours from depleted to fully charged.
  • Ultra-thick housing for exceptional durability and impact resistance.
  • Reverse polarity protection to protect from improper battery insertion.
  •  battery level indication and low-voltage warning.
  • Constant current circui for maintaining a stable output.



Take a Closer Look

HIGH-PERFORMANCE OUTDOOR FLASHLIGHT

FAQS

Contact Us
Q1. What is the product positioning of C5 V2.0? What are the keyfeatures?

A: Fenix C5 V2.0 is a high-performance outdoor flashlight. Its key features include:

USB Type-C port supports up to 2A charging; 2 hours from depleted to fully charged.

1800 lumens maximum output and 327 meters maximum beam distance.

Powered by an included 2600mAh 18650 rechargeable battery and compatible with two CR123A batteries.

Q2. What kind of LED is used in C5 V2.0? Does Fenix offer to replace LED?

A:  Utilizes one Luminus SST40 LED, with a lifespan of 50,000 hours.

Fenix does not provide LED replacement services for the time being, and users are not recommended to replace the LEDs independently, which may affect product performance and cause product damage.

Q3. What is the color temperature of C5 V2.0?

A: Around 6500K.

Q4. What is the operating voltageof C5 V2.0?

A: 2.8 - 8.4 V.

Q5. Is C5 V2.0 rechargeable? How long is the charging time?

A: Yes. The C5 V2.0 is rechargeable via its USB Type-C charging port. The batter level indicator will display red while charging and will turn green when fully charged. The normal charging time of the included battery is about 2 hours from depleted to fully charged.

Q6.How to prevent accidentally activate the C5 V2.0?

A: The C5 V2.0 features a lockout function.

Lock: With the light turned off, double click the side switch within 0.5 seconds, the light will blink twice in Low output to indicate the locked status.

Unlock: With the light locked, double click the side switch within 0.5 seconds, the light will activate in Low output to indicate that the light is unlocked.

Note: In locked status, any operation other than battery level indication and unlocking will activate two blinks in Low output to indicate the locked status.

Q7. Why does the C5 V2.0 downshift to a lower mode after being used for a while and the higher mode cannot be selected?

A: There are two reasons:

1. Intelligent Overheat Protection

The flashlight will accumulate a lot of heat when used at high output for extended periods. When the flashlight reaches a temperature of 60°C/140°F or above, it will automatically and gradually step down its output level to reduce the temperature.

2. Low-voltage Warning

When the voltage level drops below the preset level, the flashlight is programmed to downshift to a lower brightness level until the lowest output is reached.

Q8. Why does the C5 V2.0 happen to flicker?

A: The reasons that may cause the flashlight to flicker, shine intermittently or even fail to illuminate:

1. Poor battery level.

Solution: Recharge or replace the battery.

2. The contact or contact point of the battery or flashlight is dirty.

Solution: Clean the contact points with a cotton swab soaked in rubbing alcohol.

If the above methods don't work, please contact your authorized distributor.

Q9. What are the optional accessories for C5 V2.0?

A: The C5 V2.0 comes with a lanyard. Other compatible accessories: AOT-03 traffic wand, AOT-M traffic wand, AOD-M diffuser tip, ALP-10L flashlight holster, ALB-10 quick-release bike mount, ALD-05 helmet flashlight holder.

Q10. What should I do when the C5 V2.0 needs repair?

A: 1. 15-day replacement: Fenix will replace identical or equal products with documented manufacturing defects within 15 days of purchase.

2. 5-year free repair: Fenix will repair a light free of charge within 5 years of purchase if problems develop with normal use.

3. Lifetime limited warranty: If repair is required after 5 years from the date of purchase, Fenix will charge for parts. The total repair fee is dictated by the cost of the replaced materials.

4. Warranty certificate: Please keep the warranty card in contacting the authorized distributors for after-sale maintenance, Fenix will provide service support to the distributors.
